The second way through which you can mirror any object is through the scale tool of SketchUp. So it totally depends upon you how you want to mirror your component, and according to your requirement, you can choose anyone of the three options for your component. On the other hand, if you go with Component’s Blue option of Flip along to mirror this component from other side. Now I will first select the component and then click on Component’s Red option.Īnd it will flip like this along with the red axis. That means if you want to mirror this object along the Red axis, then go with the Component’s Red option for mirroring along with the Green axis, go with Component’s Green option, and so on. Here in this option, you will find Component’s Red, Component’s Green, and Component’s Blue options. Now this time, go to the Flip Along with the option of scroll down list. Now select this object and again make right-click. Once you click on this option, it will ask you to name your component, and I will name it as a mirror object, then click on Create button of this dialog box. Click on the Make Component option of the drop-down list. Now I will make this selected object as a component and, for that, select the whole object and then make right-click. You can also have a Mirror extension from the Extension warehouse and use that as a mirror tool. You can also make a copy of any object and then mirror it. There is no specific tool with the name Mirror tool in SketchUp, but we can do a mirror of objects through several ways. So let me explain to you some of the ways in a very exciting manner through which you can do this. For doing a mirror of any object or for making the mirrored object of any component, you should understand some of the features and parameters of different tools as well as the methodology of this software.
Mirror sketchup download#
You can also use Mirror extension for doing this work for your components, and you can download it from the Extension Warehouse of this software. There are a number of ways through which you can mirror any object or component in this software. Thanks to him for this great plugin.SketchUp Mirror is a process through which you can reflect any object to the opposite side of it for different types of purposes.
You can download the plugin directly here, or go to the original thread by the author TIG. Then you will need to pick the 3 points that define the mirror plane, and at the end you will have te option to choose to either keep or erase the source object. To use the plugin (after saving it to your plugins folder) select the object you want to mirror and go to Plugins -> Mirror Selection. This plugin is very easy to use and allows us to select the mirror plane and also to choose if we want to keep the original object or delete it after the mirror operation.
The third method is to use the Mirror.rb Plugin.Again, we can´t control the mirro plane, it has to be one plane defined by the faces of the bounding box of the object. Select one of the grips (using the grips on the center of the faces of the object's bounding box is the best way to go) and type "-1" as the scale value on the Value Control Box (VCB). The mirror plane has to be one of the planes defined by the center of the object. The negative part of this is that yo can't select the mirror plane. We can select the object we want to mirror, right click on it and select "Flip Along:" This will give us the chance to select which plane (red, green or blue) of the object to use as a mirror plane.Two of them can be done with the standard SketchUp installation, the third one (and probably the best) requires a Plugin. There are to me 3 methods to mirror objects. Mirror is not a standard tool in SketchUp, but that is probably because there are several ways to Mirror objects using other methods. There are several ways to mirror objects in SketchUp
